NETBOX Axial II Comfort

The NETBOX Axial II Comfort is a high-quality built-in socket that can be opened by pressing on the lid, thereby providing access to power, communication and data modules. Once all electrical equipment is connected to the NETBOX, it can also be closed during operation and guarantees an unhindered workflow. The NETBOX Axial II Comfort modules can be configured individually.

Colors
silver
Request now
NETBOX Axial Comfort new version
Keyfacts Examples Gallery Accessories Downloads
Technical Details
  • Easy access of cables through cover with rubber lip
  • Hinged aluminum cover
  • GST-18 connector
Characteristics
  • Especially suited for one-sided operation only
  • Unhindered work process possible when NETBOX is not used
  • Variable length
  • Flexibility through the use of interchangeable modules
Methods of fitting
  • Latching mechanism
  • Panel thickness: 10-45 mm
Material
  • Mounting frame: Aluminium / Plastic
  • Module unit: Plastic
Colors
  • Mounting frame: silver
  • Module unit: black

*Special colors

Example Configuration

MBC3G2201Z
NETBOX

Item number MBC3G2201Z

Casing

For 3 modules, the modules are black, the chassis is in silver. Cable exit with grey rubber.

Cutout dimension

245,5 x 155 mm

Power supply

Male GST 18/3 connector (on the left end side). Power output: Female GST 18/3 connector (on the right end side).

Wiring

1,5 mm²

Fitting

2 x Schuko (vertical)

1 x USB-charger Type A + C, 65 W

MBC4G2401Z
NETBOX

Item number MBC4G2401Z

Casing

For 4 modules, the modules are black, the chassis is in silver. Cable exit with grey rubber.

Cutout dimension

298,5 x 155 mm

Power supply

Male GST 18/3 connector (on the left end side). Power output: NO output!

Wiring

1,5 mm²

Fitting

2 x Schuko (vertical)

1 x USB-charger Type A + C, 65 W

2 x RJ45 Cat. 6 shielded (Nexans). Input data: 2 x patch-cord with male RJ45-connector, cable length app. 3500 mm

MBC4G2901Z
NETBOX

Item number MBC4G2901Z

Cables / connections are at the back of the box (if possible).

Casing

For 4 modules, the modules are black, the chassis is in silver. Cable exit with grey rubber.

Cutout dimension

298,5 x 155 mm

Power supply

Male GST 18/3 connector. Power output: NO output!

Wiring

1,5 mm²

Fitting

2 x Schuko (vertical)

2 x RJ45 Cat. 6 shielded (Nexans). Input data: 2 x patch-cord with male RJ45-connector, cable length app. 3500 mm

1 x HDMI. Input HDMI: 1 x HDMI-cable with male HDMI-connector, cable length app. 2900 mm

NETBOX Axial II Comfort
NETBOX Axial II Comfort open in the desk with laptop.

General Product and Material Information

Markings and approvals Axial II Comfort
